The mechanical ID scarfer includes a tool assembly which mounts two copy rollers on its top. The pressure needed for removing the weld bead is transferred from a leaf spring assembly to a lifting lever featuring a pressure roller. Adjustment is easy and affected through the open seam tube. A fine adjustment feature is used to provide continuous cutting ring height adjustment on the welding line through the open seam tube. Further more our cutting ring cooling features a significant increase in service life.

Click to enlarge.

Tools featuring the cutting ring cooling are now available for 15 mm tube inside diameters. Coolant lines are enclosed within the scarfer body thus preventing mechanical damage.

  • Model features a leaf spring system on a pressureroller equipped roller arm. This feature applies the amount of contact pressure necessary for removal of weld spatter accumulations, and permits working range adjustment
  • Hassle-free contact pressure adjustment from the top of the tool through the open seam tube
  • Continuous fine adjustment of cutting ring height from outside, through the open seam tube
  • Indirect roller lubrication and tool cooling provided by the emulsion present in the tube
  • A turnbuckle sleeve connects the inside tube scarfer to the impeder or extension rod
  • Cutting ring cooling is available for tools starting with model nos. F 015 018 – 10.000 to F 095 125 – 11.000. This feature significantly increases service life and is also adjustable starting with model F 038 051 – 12.000 (Designation: F 015 018 – 10.000 K => K = Cooling)
